KS3 Engineering Project - USB Lamp

KS3 Engineering Project - USB Lamp

Work in Progress! Engineering scheme of work for a USB powered lamp aimed at Year 7. One lesson per week over six weeks , 1.25 hours per lesson. Mostly making - no design element. Theoretical skills: - Woods - Product Analysis - Design Specification - Evaluation Practical skills: - Measuring - Marking Out - Cutting - Milling - Drilling - Joints (Dowel and Mortise and Tenon) - Soldering - Staining Extended writing evaluation at end, review week used to improve any written work and present their work orally.
Philipajones
KS3/4 Sketching Skills Full Scheme of Work and Resources

KS3/4 Sketching Skills Full Scheme of Work and Resources

This unit has been designed for Year 9 pupils to build confidence in sketching. Pupils learn about basic skills and build upon these each lesson. Pupils will use the DTDOT/DTMicroDOT when sketching in isometric. Applied activities include the design of earbud headphones, a hairdryer and a fragrance bottle. At the end of the unit pupils complete a product analysis on a three-pin plug.
Philipajones
KS3 Passive Amplifier Project

KS3 Passive Amplifier Project

A passive amplifier product design project designed for Y8. Students are given three identical pieces of softwood that they sandwich together, the centre piece is cut specifically for their mobile phone to slot into, the front and centre are then bored using a Forstner bit for the sound to amplify, then slots cut to join the bores to the mobile phone speakers. Pupils conduct primary research on a selection of pre-made amplifiers, come up with initial ideas, use a Pugh Matrix to select an idea, develop that idea and then manufacture.
Philipajones
KS3 Engineering Project - USB Lamp

KS3 Engineering Project - USB Lamp

Work in Progress! Engineering scheme of work for a USB powered lamp aimed at Year 7. One lesson per week over six weeks , 1.25 hours per lesson. Mostly making - no design element. Theoretical skills: - Woods - Product Analysis - Design Specification - Evaluation Practical skills: - Measuring - Marking Out - Cutting - Milling - Drilling - Joints (Dowel and Mortise and Tenon) - Soldering - Staining Extended writing evaluation at end, review week used to improve any written work and present their work orally.
Philipajones
KS3 STEM Rocket Design Project

KS3 STEM Rocket Design Project

A 5/6 week project that investigates different aspects of rocket design, each lesson aims to address a different aspect including fin design, aerodynamics and mass. A water rocket launcher is used in the school playground. https://www.amazon.co.uk/Aquapod-Bottle-Launcher-Fires-Bottles/dp/B005KSHKNW
Philipajones
WJEC L1/2 Engineering Unit 2 Resources (Lamp)

WJEC L1/2 Engineering Unit 2 Resources (Lamp)

Set of Engineering drawings for a lamp, inspired by WJEC exemplar materials, also includes an exploded animation and a progress checklist. Skills: - Lathe (upright bars and thumb screws) - 2D/3D CAD - Laser Cutting - Tapping - Marking out - Drilling - Bending - Filing - Joining with solvent cement - Assembly - Soldering Contains 12 LED array from htttp://www.startdesigning.co.uk
